GENESIS® Commercial D2

GENESIS<sup>®</sup> Commercial D2


Product description

Flexible PE ducting, food grade

Material:
Polyethylene, translucent

Single Length:
15 m

Temperature Resistance:
– 40° up to + 60° C

Applications:
Suction and transport of liquids and material especially in food industry

Properties:
Smooth bore, crush recoverable, good chemical resistance, excellent vacuum resistance, rot-proofed, food grade acc. to EG regulation no. 1935/2004 and no. 10/2011, FDA standard 21 CFR 177.2600 and 178.2010, approval confirmed by an independent testing institute for the whole hose acc. to EG regulation no. 10/2011 for Food simulant D2 for fatty food (vegetable oil, like olive oil)

Stand 04.06.2020

Technical Data
Dia.
(mm)
Weight
(kg/m)
Wall
Thickness
(mm)
Bending
radius
(mm)
Max.
Work.Press.
(bar)
Max.
Vacuum
(bar)
32 0,35 0,7 48 0,80 0,85
38 0,40 0,7 57 0,75 0,85
51 0,50 0,7 76 0,70 0,85
63 0,90 1,3 95 0,65 0,80
76 1,10 1,3 114 0,60 0,80
